JIS G3468 SUS304TPY SUS304LTPY SUS309STPY SUS310STPY SUS315J1TPY Stainless Steel Tubes
Large Diameter Welded Stainless Steel Pipes for Low Temperature
Material
The JIS G3468 standard specifies the requirements for large diameter welded stainless steel pipes, particularly for low-temperature applications. The materials covered under this standard include various grades of stainless steel, each with unique properties suited for specific environments.
Specification
The specification outlines the dimensions, tolerances, and mechanical properties required for the stainless steel tubes. These tubes are designed to withstand low temperatures while maintaining structural integrity.
Key Features
- Corrosion Resistance: Excellent resistance to oxidation and corrosion.
- Low-Temperature Performance: Designed for applications in cryogenic environments.
- Weldability: Suitable for welding, ensuring strong joints and durability.
- High Strength: Maintains strength at low temperatures.
Chemical Composition
| Grade | C (%) | Si (%) | Mn (%) | P (%) | S (%) | Cr (%) | Ni (%) | Mo (%) |
| SUS304TPY | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 18.0-20.0 | 8.0-10.5 | - |
| SUS304LTPY | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 18.0-20.0 | 8.0-10.5 | - |
| SUS309STPY | ≤0.20 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 22.0-24.0 | 12.0-15.0 | - |
| SUS310STPY | ≤0.25 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 24.0-26.0 | 19.0-22.0 | - |
| SUS315J1TPY | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 16.0-18.0 | 10.0-12.0 | 2.0-3.0 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness (HB) |
| SUS304TPY | ≥205 | ≥520 | ≥40 | ≤187 |
| SUS304LTPY | ≥205 | ≥520 | ≥40 | ≤187 |
| SUS309STPY | ≥240 | ≥600 | ≥30 | ≤200 |
| SUS310STPY | ≥250 | ≥700 | ≥25 | ≤210 |
| SUS315J1TPY | ≥220 | ≥550 | ≥35 | ≤190 |
Steel Grade
The steel grades specified in JIS G3468 are designed to meet the requirements for various applications, particularly in low-temperature environments. Each grade offers distinct advantages based on its chemical composition and mechanical properties.
Application
These stainless steel tubes are widely used in industries such as:
- Cryogenic applications
- Oil and gas pipelines
- Chemical processing
- Power generation
- Food and beverage processing
Possible Alternative Grades
While the specified grades are optimal for low-temperature applications, alternative grades may include:
- SUS316: Offers better corrosion resistance.
- SUS321: Provides improved high-temperature stability.
- SUS310S: A lower carbon version of SUS310, suitable for high-temperature applications.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
